WNS 2ton Steam Boilers

1. Boiler proprietary technology Full wet back combustion chamber, combustion chamber and rear tube plate trigger edge butt joints, boiler 100% full butt welding, the lowest stress, more reliable quality. 2. Large diameter corrugated furnace chamber Boiler combustion chamber consists of a large diameter corrugated furnace chamber, large combustion space, fuel combustion, effective absorption of thermal expansion, large radiation heating surface.

3. Sufficient heat The heating area of the boiler is designed and configured according to the design of ≥25m/steam tonne, fully absorbing the effective heat, with low exhaust temperature and small heat loss to ensure sufficient output and high efficiency.

4. High quality of steam Large diameter pot shell, large water capacity, strong adaptability to load changes, stable output; steam space volume, steam-water interface and the net distance between the steam outlet is high enough, the steam humidity is small. 5. Safe enough time to drop water The combustion chamber of the boiler is arranged in a low position, and the water level is determined in accordance with national regulations, while the water level fluctuation time is strictly in accordance with the international common norms and standards, and there is sufficient space for safe precipitation to ensure that the boiler is safe to operate. 6. Multi-functional safety and explosion-proof device Boiler rear panel is equipped with an explosion-proof device connected to the furnace chamber, to prevent the fuel in the furnace chamber in the event of a violent deflagration, the release of high energy generated instantly, can be automatically reset, and at the same time has a fire view mirror and the functional role of the access channel, the use of combustion flame adjustment in the operation of the furnace chamber inspection, maintenance and convenience. 7. Convenient access to the boiler The top of the boiler is equipped with a manhole, boiler front and back end of the lower part of the unique hand hole device, easy to pot device and the bottom of the boiler inspection, cleaning.

8. before and after the smoke box sealing unique The smoke box adopts double-opening smoke box door, easy to open, multi-stage labyrinth sealing, sealing material special, good compression, completely blocking the leakage of flue gas, can be reused. 9. Reliable pressure and water level protection Boiler pressure, water level set multiple control protection, as well as over-smoke temperature protection to ensure the safety of boiler operation. 10. Leading level of automatic control

Boiler controller adopts Siemens/Delisi electrical components, reliable performance. The controller has three forms: ordinary type, Chinese and English menu type with liquid crystal display, and touch screen type with man-machine dialogue remote control.

Main Parameter

Certificate
